Control Arm (850 AWD) - Revised Method for Replacing: Overview

SECTION
6

GROUP
61

NO.
805

DATE
July 1996

Replacing 850 AWD control arm 850

Canadian cars only

REFERENCE: TP 4314201, section 4(43, 46) AWD (ALL WHEEL DRIVE); 850 1997-

Replacing 850 AWD control arm

General information

Because the mountings in the sub-frame control arm on the AWD are different from those on other 850 models a new method for replacing the control arm has been developed.





This Service Bulletin describes the method for replacing the control arm for the 850 AWD.

WARRANTY STATEMENT: Claims may be submitted under the New Car Limited Warranty when a manufacturing defect is present using claim type: 01

Operation No. Labor description Time allowance

61208-2 Control arm, remove/replace 1 side 0.6 hr

61216-2 Control arm, remove/replace 2 sides 11 hr
