Fault-Tracing Information

Fault-tracing information

Condition




The defroster button (rear window / door mirrors) should be ON (orange LED on).

Possible source
- Fault in fuse no. 12 (15A) in the passenger compartment integrated relay / fusebox (11/B).
- Fault in fuse no. 3(25A) in the engine compartment integrated relay / fusebox (11/A).
- Defective defroster relay.
- Open-circuit or short-circuit in the cable between the ECC control module and the defroster relay in fusebox (11/B).

Fault symptom[s]
- The rear windshield / door mirrors do not demist.
