Audio/Lighting - Am Band Interference With DRL ON

Title: Interference on the AM-band from DDRL Position Lamps

Ref No: US23942.2.0 en-US

Issuer: -

Partner: 3 US 7510 Volvo Cars North America

Func Group: 3952

Func Desc: Antenna

Status: Released

Status Date: 2011-07-12

Issue Date: 2011-07-06

Reference:

Attachment:





Vehicle Type





CSC Customer Symptom Codes

DTC Diagnostic Trouble Codes

Text
CSC = Customer Symptom Code

If using a printed copy of this document, always check for the latest online version

DESCRIPTION:

Certain vehicles equipped with DDRL (Dedicated Day Running Lights) LED, may exhibit interference on the AM-band when the DDRLs are illuminated. This interference may be present on any AM-frequency.

PRODUCT MODIFICATION:

The service and production solution is a new version of the DDRL position lamps.

S40/V50 Left Hand P/N 31353107
S40/V50 Right hand, P/N 31353108
C30 Left hand, P/N31353109
C30 Right Hand, P/N 31353110

Service

If the above describes symptom occurs with a vehicle with DDRL position lamps, the DDRL position lamps may need to be replaced to the new type described above.

VSTG OPERATION NUMBER:
35230-2 Front indicator/parking unit replace
